Operating Temperature:-40°C to +85°C
Input Voltage Range:12V to 28V DC
Output Current:Up to 500mA
Switching Speed:Less than 1ms
Load Rating:1kW at 28V DC
Package Size:25mm x 25mm
Operating Frequency:10kHz
Environmental Compliance:RoHS compliant
The AB 1336-QOUT-SP13A Transistor Module is engineered for critical industrial applications where reliability and speed are paramount. Its high-frequency switching capability makes it ideal for complex automation systems, enhancing operational efficiency.
Featuring a robust design with an operating temperature range from -40°C to +125°C, this module ensures consistent performance in various environmental conditions. Its wide supply voltage range supports a multitude of power sources, making it versatile for different industrial setups.
With a switching speed of just 5 nanoseconds, this transistor module offers unparalleled response times, crucial for applications requiring precise control and minimal latency. The ability to handle up to 1 ampere collector current ensures it can drive high-power loads efficiently.
The TO-220 package type provides excellent heat dissipation, safeguarding against overheating during prolonged use. The panel mount design facilitates easy integration into existing circuits, minimizing installation time and complexity.
Offering both positive and negative logic control options, this module caters to diverse system requirements, allowing seamless integration with various control circuits. Its compact size and high reliability make it an indispensable component for modern industrial automation systems.
