Brand:ABB
Model:3HNE00001-1/07
Module Type:Ethernet Board
Technology:DCS Communication
Operating Voltage:12-48 V DC
Data Transfer Rate:Up to 10 Mbps
Protocol Compatibility:MODBUS, CANopen, DeviceNet
Dimensions:125mm x 84mm x 54mm
Power Consumption:≤ 1.5W
Operating Temperature:-20°C to +70°C
Storage Temperature:-40°C to +85°C
Connection Type:RS-485/RS-232
Environment Resistance:IP20
Number of Channels:4
Input Output Configuration:DIx4/DOx4
Wire Size:0.5-2.5 mm²
Mounting:Panel Mount
Connection Interface:M12 Connector
Software Compatibility:ABB Ability, Third-party SCADA Software
Certifications:CE, UL, IEC
The ABB 3HNE00001-1/07 Ethernet Board DCS Module is designed to enhance operational efficiency and reliability in demanding industrial environments. This high-performance module seamlessly integrates into existing DCS systems, offering superior data transmission capabilities over Ethernet.
Featuring a compact yet rugged design, it ensures durability and ease of installation, making it suitable for a wide range of applications from manufacturing floors to process control systems.
With support for IEEE 802.3 standards, this Ethernet board delivers fast and reliable data transfer rates, ensuring smooth operation even under heavy network loads. Its compatibility with TCP/IP and UDP protocols facilitates seamless communication with various network devices.
Operated within a temperature range of -20°C to +60°C, this module is engineered to withstand harsh industrial conditions, guaranteeing consistent performance throughout its operational life.
In terms of power consumption, the ABB 3HNE00001-1/07 Ethernet Board DCS Module is energy-efficient, consuming less than 5 watts. This not only reduces operating costs but also minimizes environmental impact.
Equipped with a robust RJ45 connection type, the module ensures secure and stable data connections, enabling reliable data exchange between devices. Its dimensions of 172mm x 100mm allow for versatile placement within control panels or enclosures.
