ABB AB 22A-D2P3N104 PowerFlex 4 AC Drive, High-Efficiency Variable Frequency Drive

Operating Voltage:480V AC

Phase:3

Power Rating:14 kW

Motor Horsepower:7.5 HP

Frame Size:C

Enclosure Type:Panel Mount – IP 20, NEMA/UL Type 1

Interface Module:Full Numeric LCD

Control Features:Standard control features with a full numeric LCD interface

Network Compatibility:Devicenet network type

Frame Types:Standard C, D, & E frames

Rating with Filtered Frames:Optional for Frames A & B

Manual:No manual equipped

Brake IGBT:Yes with Resistor: Yes

    The ABB AB 22A-D2P3N104 PowerFlex 4 AC Drive stands as a cornerstone in industrial automation, engineered to enhance operational efficiency and reduce energy consumption. Its robust design ensures seamless integration with existing systems, making it a versatile solution for a wide array of applications from packaging lines to automotive assembly.

    Featuring a state-of-the-art control interface, this drive offers intuitive operation and advanced diagnostics, enabling operators to monitor and adjust parameters in real-time for optimal performance. The enhanced key panel provides direct access to critical functions, allowing for quick adjustments without the need for complex software interfaces.

    Designed with industry-leading reliability in mind, the AB 22A-D2P3N104 is built to withstand harsh environments and demanding workloads, ensuring minimal downtime and maximum productivity. Its modular construction allows for easy upgrades and maintenance, facilitating a smooth evolution alongside technological advancements without compromising system integrity.

    This AC Drive is compatible with a variety of motors, making it adaptable to different power requirements and speed needs. It supports up to 10 horsepower, providing ample power for most industrial machinery. Its compatibility with Ethernet/IP networks enables seamless communication with other smart devices in the production line, enhancing overall system integration and data exchange capabilities.

    With an operating temperature range from -10°C to +50°C and an ambient humidity level of 5% to 95% without condensation, this drive is suitable for diverse industrial settings. Its IP20 NEMA/UL Type 1 protection class ensures safety in a range of environmental conditions, safeguarding against dust and splash water, contributing to its longevity and durability.
