ABB ACS800 Series 304/704 Power Drive Board

Power Rating:304/704 kW

Operating Voltage:AC 400V to 690V

Inverter Efficiency:Up to 98%

Control Protocol Compatibility:Modbus, EtherCAT, Profinet

Cooling System:Fan-cooled

Max Load Capacity:200 HP

Environmental Conditions:-25°C to +50°C operating temperature

Certifications:CE, UL, ISO 9001, IEC 61800-3

    The ABB ACS800 Series 304/704 Power Drive Board is engineered for seamless integration into complex industrial control systems, offering unparalleled performance and robustness. It is equipped with advanced control algorithms that ensure precise speed and torque control, making it ideal for demanding applications requiring high precision and reliability.

    Featuring an extensive power rating from 18.5 kW up to 750 kW, this drive board can handle a wide range of machinery, from small conveyors to large industrial pumps or fans. Its broad operating temperature range (-20°C to +60°C) ensures continuous operation under diverse environmental conditions.

    With its AC input voltage flexibility (380-480V), the ABB ACS800 304/704 can be easily adapted to different electrical systems, enhancing compatibility across various industries. The output current capacity of up to 1600 A ensures efficient power delivery to connected equipment.

    Equipped with IP21 protection class, the drive board offers basic protection against dust and splashes of water, safeguarding its operation in industrial environments. Its communication interfaces support Ethernet and Modbus TCP/IP protocols, facilitating easy integration with existing control systems and remote monitoring capabilities.

    The drive board supports both V/F Control and Vector Control modes, providing users with flexibility to choose the most suitable control strategy based on their specific application requirements. This ensures optimal performance and energy efficiency across a variety of industrial processes.
