Brand & Model:ABB HEIR 445976 R1 UN 0950A-P
Technology Type:PCB Circuit Board
Operating Environment:Industrial Control Systems
Max Temperature Rating:85°C
Operating Voltage Range:12-36V DC
Input Current:10mA – 1A
Connection Type:Standard Socket
Mounting Style:Panel Mount
Material:Ruggedized Aluminum Alloy
Certifications:CE, UL, RoHS Compliant
The ABB HEIR 445976 R1 UN 0950A-P PCB Circuit Board is engineered with precision and robustness, ensuring seamless integration into complex industrial control systems. Its compact design and durable materials make it suitable for environments ranging from freezing temperatures to high heat conditions, ensuring reliable operation under extreme conditions.
Featuring a double-sided circuit board structure, this PCB supports a wide range of components, allowing for intricate circuit designs that enhance system functionality and efficiency. The use of high-quality FR-4 material ensures electrical insulation and mechanical stability, making it ideal for applications where electrical isolation is crucial.
With a broad operating voltage range of 24V DC, this circuit board is compatible with various power sources commonly found in industrial settings. Its operating frequency up to 1 MHz enables fast signal transmission and processing, crucial for high-speed data exchange in control systems.
The connection type, featuring both pin header and surface mount technology (SMT), offers flexibility in assembly and compatibility with different system architectures. This flexibility ensures easy integration and replacement, minimizing downtime and enhancing maintenance efficiency.
Certified for industrial use, the ABB HEIR 445976 R1 UN 0950A-P PCB Circuit Board adheres to stringent quality standards and safety regulations, ensuring reliability and longevity in demanding environments. Its lightweight design facilitates efficient handling and installation, making it a practical choice for on-site applications.
