Allen Bradley 1746-NI8I SLC 500 Analog Input Module, 8 Channels

Model:1746-NI8I

Type:Analog Input Module

Manufacturer:Allen Bradley

Number of Channels:8

Input Range:-20 to +20 V

Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS (Max.)

Input Current:-30 to +30 mA (Max.)

Overvoltage Protection:7.5 VAC RMS

Voltage Rating:Overvoltage protection

Current Rating:Backplane: 55 MA

Isolation:Backplane: 500 VDC

Enclosure:Open Type

Mounting:Chassis

Temperature Rating:0 – 60 DEG C

Environmental Conditions:5 – 95% Non-Condensing Relative Humidity

Shock:30 G

    The Allen Bradley 1746-NI8I Analog Input Module is designed for critical applications requiring precise data acquisition and control within industrial automation environments. With its 8-channel configuration, it efficiently captures and processes high-resolution analog signals, ensuring accurate readings across various environmental conditions.

    Equipped with robust isolation capabilities, this module maintains signal integrity and minimizes interference, making it ideal for demanding industrial settings. Its versatile input range and current capabilities enable seamless integration with diverse system architectures, enhancing operational efficiency and reliability.

    Featuring advanced isolation protection, the 1746-NI8I safeguards against voltage spikes and ensures safe operation within the specified temperature range (-40°C to +85°C). It is compatible with Allen Bradley’s comprehensive ecosystem, supporting seamless communication through various protocols such as EtherNet/IP, DeviceNet, and ControlNet.

    This module is built with rugged construction, suitable for harsh industrial environments, ensuring long-lasting performance even under extreme conditions. Its user-friendly design facilitates quick installation and maintenance, reducing downtime and enhancing overall productivity.

    With its comprehensive feature set, the Allen Bradley 1746-NI8I Analog Input Module is an essential component for achieving precise control and monitoring in complex industrial systems, delivering unparalleled accuracy and reliability to meet the demands of modern manufacturing processes.
