Allen Bradley 1746SC-INO4VI Volt Output SLC 500 Analog Input Module

Model Type:SLC 500

Model Number:1746SC-INO4VI

Manufacturer:Allen Bradley

Number of Channels:4 (Input), 4 (Output)

Input Type:Common Mode Voltage Range -20 To 20 V, Absolute Input Voltage +7.5 VDC / +7.5 VAC RMS (Max)

Output Range:-10 To 10 V – 1 LSB

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Input Current:-30 To 30 MA (Max)

Output Current:-10 To 10 V – 1 LSB

Absolute Input Current:-30 To 30 MA (Max)

Absolute Output Current:-10 To 10 V – 1 LSB

Backplane Current Draw:55 MA

Environmental Conditions:5 – 95% Non-Condensing Relative Humidity

Temperature Rating:0 – 60 DEG C

    Introducing the Allen Bradley 1746SC-INO4VI Volt Output Analog Input Module, a critical component for enhancing precision in industrial control systems. Designed with an advanced technology, this module offers unparalleled accuracy in voltage measurement and conversion.

    Featuring 2 channels for input, the module supports a common mode voltage range from -20 to 20 V, ensuring reliable operation across various industrial environments. Its absolute input voltage range of Plus/Minus 7.5 VDC or 7.5 VAC RMS ensures compatibility with diverse power sources.

    With a precise input range of -20 to 20 MA, this module ensures accurate data acquisition. The output range of -10 to 10 V with a least significant bit (LSB) resolution guarantees high-fidelity signal transmission.

    Equipped with overvoltage protection at 7.5 VAC RMS, the 1746SC-INO4VI is built to withstand harsh conditions. Its operating temperature range from 0 to 60 DEG C, along with non-condensing relative humidity between 5% and 95%, makes it suitable for a wide array of industrial applications.

    The shock resistance of 30 G ensures robust performance even under unexpected mechanical stresses. This Analog Input Module is a testament to Allen Bradley’s commitment to providing top-tier solutions for modern industrial automation.
