Input Channel Count:4
Output Channel Count:2
Analog Input Resolution:12-bit
Analog Output Resolution:12-bit
Input Range:-10V to +10V
Output Range:-10V to +10V
Operating Voltage:24VDC
Power Consumption:100VA @ 24VDC
Communication Compatibility:EtherNet/IP, Modbus TCP
Dimensions:118 x 70 x 87 mm (4.65 x 2.76 x 3.43 in.)
Weight:630g (1.39 lb)
The Allen-Bradley 1769-IF4XOF2/A module is a key component in industrial automation systems, providing seamless integration with CompactLogix controllers. It features four high-resolution 12-bit analog input channels and four output channels, enabling precise control over industrial processes.
Engineered for efficiency and reliability, this module operates on a stable 24VDC power supply, ensuring consistent performance across various industrial environments. Its low power consumption of up to 100 VA at 24V DC makes it suitable for applications where energy efficiency is critical.
With a maximum input current of 5 mA per channel and output current of 10 mA per channel, the 1769-IF4XOF2/A module offers a versatile range for diverse industrial control scenarios. The high resolution of 12 bits ensures accuracy and precision in data conversion.
Featuring a compact design with dimensions of 118 x 70 x 87 mm and weighing 630 g, the module is easy to install and integrate into existing control systems, whether mounted on a panel or DIN rail. This modular design supports flexible installation options and space optimization.
Ideal for applications in food processing, petrochemicals, pulp and paper, automobile manufacturing, water and wastewater management, oil and gas extraction, and power generation, the Allen-Bradley 1769-IF4XOF2/A module enhances operational efficiency, precision, and reliability in a wide range of industrial sectors.
