Extended Product Type:Sensor
Product ID:BES516-356-E5-Y-S4/BES516-356-E5-C-S4
Type Designation:Inductive Sensor
Style:M12x1
Installation:Non-flush / Flush mounting
Range:8mm / 2mm
Switching Output:PNP normally open (NO)
Switching Frequency:200 Hz / 3500 Hz
Connection:Connector, M12x1 connector, 4-pin
Operating Voltage:10…30 VDC
Dimensions:Ø 12 x 45 mm
The Balluff BES516 series of inductive sensors provides a robust solution for detecting metal objects in industrial environments. With a versatile design, these sensors can be installed either non-flush or flush, making them suitable for a wide range of applications from automotive manufacturing to packaging machinery.
For non-flush mounting, the BES516-356-E5-Y-S4 offers an extended sensing range of up to 8 mm, ideal for applications requiring longer detection distances. On the other hand, the BES516-356-E5-C-S4 is designed for flush mounting, delivering high-speed switching capabilities with a range of 2 mm, perfect for high-frequency detection tasks.
Both models feature a PNP normally open (NO) switching output and operate within a wide input voltage range of 10 to 30 VDC, ensuring compatibility with a variety of control systems. Their compact dimensions make integration seamless into existing machinery without compromising on performance or reliability.
With durable construction and high resistance to environmental conditions, these sensors are built to withstand the rigors of industrial use, providing consistent performance over time. Choose the Balluff BES516 series for precision, reliability, and flexibility in your next industrial automation project.
