Beckhoff EK1101-0000: Advanced EtherCAT Coupler with Integrated ID Switch

EtherCAT Interface:Yes

ID Switching Capability:Integrated

Data Transfer Rate:100 Mbit/s

Bus Coupling Capacity:Up to 1024 devices

Power Supply:DC 12V to 30V

Operating Temperature Range:-20°C to +70°C

Environmental Compliance:IP20

Dimensions (WxHxD):72 x 72 x 35 mm

Weight:Approx. 45 g

    The Beckhoff EK1101-0000 EtherCAT Coupler is engineered to meet the stringent demands of modern industrial automation environments. Its innovative ID switch feature simplifies network setup by automatically recognizing and selecting the correct node ID, thus eliminating the need for manual configuration and reducing setup errors.

    This coupler supports 10/100Base-TX Ethernet interface, ensuring compatibility with a wide range of industrial equipment and protocols. Its high data transfer rate of up to 100 Mbit/s guarantees fast and reliable communication, critical for real-time control applications.

    Equipped with a robust RJ45 connector, the coupler ensures secure and stable network connections, even under harsh environmental conditions. The operating temperature range from -20°C to +70°C makes it suitable for various industrial settings, from cold storage facilities to hot manufacturing floors.

    The compact design of the coupler, measuring 75 x 50 x 35 mm and weighing only 55 grams, allows for easy installation and integration into tight spaces. Its low power consumption of 30 mA at maximum ensures efficient use of electrical resources, contributing to energy savings and sustainability.

    Designed with durability and reliability in mind, the Beckhoff EK1101-0000 EtherCAT Coupler meets international safety and quality standards, providing peace of mind for users. It is backed by Beckhoff’s commitment to customer satisfaction, offering comprehensive technical support and long-term availability.
