Measurement Range:±1.0 mm (.04 in) Static, 0 to 500 μm (.02 in) Dynamic
Temperature Error:Zero point: 200 mV / 100˚ K
Operating Temperature Range:-25°C to +70°C (-13°F to +158°F)
Resolution:0.01 mm (.0004 in)
Operating Voltage:12VDC or 24VDC
Current Consumption:Max. 50mA @ 12VDC, Max. 30mA @ 24VDC
Connectivity:M12 Connector
Material:Stainless Steel
Weight:0.4 kg (Approx.)
The EMERSON PR6424/000-100 CON021 eddy current sensor is designed for critical industrial control applications requiring high precision and reliability. Its advanced eddy current technology ensures accurate distance measurements in a wide range of operating conditions.
Featuring a compact yet robust design, this sensor is IP67 rated for protection against dust and water ingress, ensuring reliable performance in harsh environments. It is capable of measuring distances up to 1.0mm statically and dynamically within a range of 0 to 500μm.
With its ±1.0 mm static measuring range and 200 mV/100˚K temperature error zero point, the PR6424/000-100 CON021 guarantees exceptional accuracy even under varying temperatures and environmental conditions.
The sensor’s ability to operate at 24V DC and its frequency response of 4 kHz make it suitable for integration into complex industrial automation systems, providing real-time, precise data for process control and monitoring.
Equipped with an initial air gap of 0.5 mm, this sensor can accurately measure objects without direct contact, reducing wear and tear on both the sensor and measured object. Its lightweight design (0.4 kg) facilitates easy installation and maintenance.
