Sensor Type:Eddy Current
Measurement Range:2 mm (80 mils) Static | 0 to 500μm (0 to 20 mils) Dynamic
Initial Air Gap:0.5 mm (20 mils)
Linear Measurement Range:2 mm (80 mils)
Temperature Range:-40°C to +125°C
Resolution:0.001 mm (0.04 mils)
Accuracy:+/- 1% of full scale
Operating Voltage:DC 12V – 30V
Current Consumption:Typical 5mA, Max 15mA
Response Time:Less than 5ms
Operating Humidity:5% to 95% non-condensing
Storage Conditions:-40°C to +150°C
Material:Aluminum Housing, Stainless Steel Probe
Weight:0.32kg (PR6423/00R-010 + CON021) | 0.26kg (PR6423/011-131 + CON031)
Introducing the EPRO PR6423/00R-010 CON021 & PR6423/011-131 CON031 Industrial Sensor, designed to withstand harsh industrial conditions and deliver unparalleled accuracy in linear measurements.
This sensor is meticulously crafted from high-grade stainless steel, ensuring durability and resistance against corrosion in even the most demanding environments.
Featuring an advanced air gap design, the sensor provides precise measurement within its linear range of 2mm (80 mils) with an initial air gap of 0.5mm (20 mils), making it ideal for precise control systems.
Operational excellence is further enhanced by its exceptional temperature error tolerance of +/- 200 mV / 100˚ K, ensuring reliable performance across a broad temperature spectrum (-40°C to +85°C).
With an IP67 rating, this sensor is protected against dust and water ingress, making it suitable for outdoor or wet environment applications without compromising on performance.
Ease of integration is ensured through standard connector compatibility, allowing seamless connection to various industrial systems and control panels.
