Compatibility:DC-300 and Similar Drive Systems
Series:531x
Interface Type:D3 +5V
Encoder Process Interface:Yes
Secondary Board Number:531X134EPRBHG1
Power Supply Voltage:5V
Terminal Strip:3-Screw
Monitor Capability:Motor Speed Monitoring
Adjustment Feature:PI-tach Scale Adjustment
Component Count:Over 20 Jumpers, 4 Resistor Networks, 7 Potentiometers
The GE Fanuc F31X134EPRBHG1 is a highly adaptable interface board designed for use in industrial environments, ensuring smooth integration into existing systems. It is part of the renowned 531x series, known for its flexibility and robust performance in various industrial settings.
This circuit board is specifically engineered for compatibility with the DC-300 drive system and other similar drives, making it an excellent choice for those seeking versatile components that can adapt to a range of applications without the need for customization.
Equipped with a 3-screw terminal strip, the F31X134EPRBHG1 offers convenient motor speed monitoring capabilities. Simply connect a voltmeter between 1 TB-1 and 1 TB-3 to accurately gauge the motor’s rotational speed, enhancing system efficiency and control.
For even finer adjustments, the board features a PI-tach scale adjustment feature that allows users to set the scale for 50% of the motor speed, ensuring precise operation tailored to specific requirements.
Featuring over 20 jumpers, four resistor network arrays, and seven potentiometers, the F31X134EPRBHG1 provides ample flexibility for configuring various functionalities. This comprehensive set of features makes it an indispensable component in complex industrial systems, offering unparalleled control and customization options.
