Pepperl+Fuchs UB500-18GM75-E6-V15 Ultrasonic Sensor

Sensing Range:30 to 500 mm

Operating Voltage:10 to 30 V DC, 10% ripple

Output Type:1 Analog output 4 mA to 20 mA

Connection:M12 x 1, 5-pin connector

Programmability:User-selectable sound lobe width, synchronization options, deactivation option, temperature compensation

Unusable Area:Very small, adjustable measuring window

    The Pepperl+Fuchs UB500-18GM75-E6-V15 ultrasonic sensor is engineered to deliver unparalleled accuracy in distance measurement tasks within industrial environments. This compact yet robust sensor is ideal for integration into automated systems requiring precise distance data.

    With an adjustable measuring window, selectable sound lobe width, and programmable input synchronization options, users can tailor the sensor’s performance to meet specific application needs. The deactivation feature ensures operational safety, while temperature compensation minimizes environmental impact on measurement accuracy.

    Featuring an Ethernet connection via Modbus/TCP and RS-485 interface for Modbus/RTU protocols, the UB500-18GM75-E6-V15 is versatile for networking in various industrial settings. This makes it compatible with open networks like PROFIBUS-DP, CC-Link, and DeviceNet for seamless integration into complex control systems.

    Designed for long-term reliability, this sensor complies with the Restriction of Hazardous Substances (RoHS) directive and the Waste Electrical and Electronic Equipment (WEEE) directive, ensuring eco-friendly manufacturing practices. Its compatibility with multiple languages enhances usability across diverse global industries.

    For optimal operation, we recommend pairing this sensor with LL50A parameters setting software, which includes a ladder program building function for advanced customization. This ensures users can easily configure and manage sensor settings according to their specific requirements.
