Rated Current (Ic):300A
Continuous Operating Voltage (Vge):600V
Switching Frequency:20kHz
Cooling Method:Thermal Pad with Forced Air Cooling
Package Type:TO-247-3
Operating Temperature Range:-40°C to +175°C
Insulation Resistance:> 100MΩ @ 500VDC
Average Forward Loss:< 0.3W @ 25°C
Introducing the Semikron SKIIP1803GB172-3DL IGBT Modules, an industry-leading choice for high-power inverter systems. These modules are meticulously engineered to deliver exceptional performance, efficiency, and durability in the most demanding industrial settings.
Featuring a compact yet robust design, the SKIIP series ensures optimal heat dissipation through its advanced water-cooling system, enabling continuous operation even under extreme temperatures ranging from -40°C to +175°C. This makes it ideal for applications requiring consistent power output in challenging environments.
With a maximum switching frequency of up to 50kHz, these modules provide a balance between speed and thermal stability, ensuring minimal power loss and extended component life. The insulation class F (155°C) guarantees reliable operation under high-voltage conditions, making them suitable for a wide range of industrial applications.
Designed with ease of integration in mind, the SKIIP1803GB172-3DL modules are compatible with various control systems, offering flexible customization options for OEMs and end-users. Their modular design facilitates quick installation and maintenance, reducing downtime and enhancing operational efficiency.
Backed by Semikron’s commitment to quality and innovation, these IGBT modules undergo rigorous testing to ensure they meet the highest standards for reliability and safety. They are designed to withstand the rigors of continuous operation, making them a preferred choice for applications such as renewable energy conversion, electric drives, and HVAC systems.
