Teradyne 949-824-01/D Industrial Circuit Board

Manufacturer:Teradyne

Model Number:949-824-01/D

Application Area:Industrial Automation

Module Category:Circuit Board

Board Type:High-Performance, High-Speed

Operating Temperature Range:-40°C to +85°C

Input Voltage:DC 12V

Power Consumption:15W

Connection Ports:RS-232, RS-485, Ethernet

Dimensions:100mm x 100mm

Weight:150g

Certifications:CE, UL

    The Teradyne 949-824-01/D Industrial Circuit Board is engineered for the most demanding industrial environments, ensuring unparalleled performance under extreme conditions. This circuit board is meticulously designed to withstand harsh operational demands, offering a robust solution for automation systems, robotics, and manufacturing equipment.

    Featuring a wide operating temperature range from -40°C to +85°C, this board is suitable for applications across various climates and terrains. It supports a maximum current of 10A, making it ideal for high-power devices requiring precise control and stability.

    With its 40-pin DIP configuration, the Teradyne 949-824-01/D provides flexible connectivity options, allowing seamless integration with existing industrial components and systems. Its compact size (100mm x 70mm) ensures efficient use of space on the motherboard, optimizing board layouts for streamlined assembly processes.

    The circuit board is equipped with advanced safety certifications including CE, UL, and RoHS compliance, ensuring compliance with international standards for electrical safety and environmental responsibility. This guarantees reliable operation in a wide range of industries without compromising on safety or sustainability.

    Incorporating cutting-edge materials and construction techniques, the Teradyne 949-824-01/D is built for longevity and reliability, backed by Teradyne’s commitment to quality and customer support. It is an indispensable component for enhancing the efficiency and reliability of industrial control systems.
