Startup Time:6 ms max.
Control Output:-10 to 10 V
Data Backup:Backup using the CPU module
External Contact Output:Servo on, driver reset and brake off
Encoder Type:Incremental encoder (phaseA/B)
Encoder Resolution:2M pps max. /4-time multiplication mode
Control System:Semi-closed loop control (with voltage output for velocity control) based on encoder feedback
External Contact Input:Limit switch, driver alarm, home
The YOKOGAWA F3NC01-0N is a high-performance positioning module designed to meet the demands of industrial automation environments. Its key design highlights include a fast startup time of just 6 milliseconds, ensuring swift response times for critical applications. Equipped with a versatile control output range of -10 to 10 V, this module provides precise velocity control necessary for various industrial processes. Data backup functionality is seamlessly integrated, leveraging the CPU module for reliable data retention during operations. Additionally, the external contact outputs enable control over servo mechanisms, driver resets, and brake disengagement, providing comprehensive operational flexibility. Built with an incremental encoder offering up to 2 million pulses per second (M pps) with 4-time multiplication mode, this module ensures accurate position tracking and feedback. Its semi-closed loop control system further enhances precision by utilizing voltage output for velocity control based on encoder feedback. With robust external contact inputs for limit switches, driver alarms, and home positions, the YOKOGAWA F3NC01-0N is an essential component for any industrial control system aiming for high reliability and efficiency.
